Description
UFP Replacement Trailing Arm 3,750lb with DB-35 Disc Brakes and Vault Hybrid Lubrication System #U43130
This replacement trailing arm works with all Trailer Buddy UFP 3750lb. models. capacity torsion axles. Mounts easily to the desired position via splines that allow ride-height adjustment. The complete assembly is ready to be bolted on to existing torsion axle with mounting bolt (included). Complete with DB-35 series Disc Brake Rotor and Caliper.
Features:
- Trailing arm, rotor, and caliper are zinc-plated for superior corrosion protection
- 9 3/4″ diameter DB-35 Rotor (Tapered)
- Standard UFP Aluminum DB-35 Caliper
- VAULT maintenance-free hybrid oil hub, requires no maintenance and is completely sealed
- Tooth and groove or spline attaches easily to any 3,750 lb UFP Torsion axle
- Mounting bolt, nut, and washer are included
- Tapered spindle size is 1 3/8″ x 1 1/16″
- Bearings and seals are pre-packed with VAULT Hybrid Oil
- 68149 Inner Bearing and 44649 Outer Bearing
- 1.68 ID Seal
- VAULT hub cap seals the hub and maintains slight pressure in hub
UFP Torsion Axle end unit trailing arm with VAULT Hybrid oil pre-packed with DB-35 Series Disc Brakes
