Trek Rail 7 E-MTB Trail Bike – 40% Off MSRP

Description

Rail 7 is a long-travel electric mountain bike built for ripping the big stuff. It features the same high-end trail tech as our analogue trail bikes, an upgraded fork, drivetrain, battery and more, plus a powerful Bosch drive system that’s basically like having your own shuttle.



Specifications

*spec applies to all sizes unless otherwise noted

Frameset

Frame	Alpha Platinum Aluminium, Removable Integrated Battery (RIB), tapered head tube, Control Freak internal routing, magnesium rocker link, Motor Armour, Mino Link, ABP, Boost148, 12 mm thru axle, 150 mm travel
Fork	RockShox Domain RC, DebonAir spring, Motion Control damper, lockout, tapered steerer, 44 mm offset, oversized crown for eMTB, Boost110, 15 mm Maxle Stealth, 160 mm travel
Shock	RockShox Deluxe Select+, 230 mm x 57.5 mm
Max compatible fork travel	170mm (580mm axle-to-crown)

Wheels

Wheel front	Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle
Wheel rear	Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12 mm thru axle
Skewer rear	Bontrager Switch thru-axle, removable lever
Rim	Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle
Tyre	Bontrager XR5 Team Issue, Tubeless Ready, aramid bead, 120 tpi, 29×2.50″
Tyre part	Bontrager TLR sealant, 180 ml/6 oz
Rim strip	Bontrager TLR
Max tyre size	Frame: 29×2.60″ Fork: See manufacturer

Drivetrain

Shifter	Shimano SLX M7100, 12-speed
Rear derailleur	Shimano XT M8100, long cage
Crank	E*thirteen E*spec Plus, 34T, 165 mm length
Cassette	Shimano Deore M6100, 10-51, 12-speed
Chain	Shimano SLX M7100, 12-speed
Pedal	VP-536 nylon platform
Max. chainring size	34T

Components

Saddle	Bontrager Arvada, steel rails, 138 mm width
*Seatpost	Size: S TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length
	Size: M, L, XL TranzX JD-YSP18, 150 mm travel, internal routing, 31.6 mm, 470 mm length
Handlebar	Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 780mm width
Grips	Bontrager XR Trail Comp, nylon lock-on
Stem	Bontrager Rhythm Comp, 31.8 mm, Knock Block, 0-degree, 50 mm length
Head set	Knock Block Integrated, 58-degree radius, cartridge bearing, 1-1/8″ top, 1.5″ bottom
Brake	Shimano 4-piston hydraulic disc, M6100 lever, M6120 calliper
Brake rotor	Shimano RT76, 6-bolt, 203 mm

Accessories

Battery	Bosch PowerTube 625
Charger	Bosch standard 4A, 220–240V
Controller	Bosch Purion
Motor	Bosch Performance CX, magnesium motor body, 250 watt, 85 Nm, 25 km/h (15.5 mph) max assist, 32 km/h for New Zealand

Weight

Weight	M – 24.01 kg / 52.94 lbs (with TLR sealant, no tubes)
Weight limit	This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
