2025 Trek Madone Slr 9 Gen 8 Carbon Smoke 1

2025 Trek Madone SLR 9 Gen 8 – Carbon Smoke Edition

$0.00

Quantity
SKU: N/A Category: Brand:

Description

The Madone SLR 9 Gen 8 is built for dominating the roads with equal parts light weight and aerodynamic speed. It’s crafted from our highest-level 900 Series OCLV Carbon that’s not only insanely light, but delivers aerodynamic shapes for crushing descents and straightaways. Lightweight IsoFlow frame technology means that Madone doesn’t sacrifice comfort for speed. This build comes ready to win with Shimano’s top-of-the-line Dura-Ace Di2 drivetrain, carbon wheels, a Trek Aero RSL one-piece carbon bar/stem and RSL Aero Bottles and Cages for more drag reduction.

*Please note – spec applies to all sizes unless listed separately

Frameset

Frame 900 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic-only routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142×12 mm thru axle
Fork Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle

Weight

Weight ML – 7.05 kg / 15.55 lbs (with TLR sealant, no tubes, no bottles/cages)
Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).

E-system

Battery Shimano BT-DN300
Charger Charging cable included

Drivetrain

Shifter Shimano Dura-Ace R9270 Di2, 12 speed
Front derailleur Shimano Dura-Ace R9250 Di2, braze-on, down swing
Rear derailleur Shimano Dura-Ace R9250 Di2, 34T max cog
*Crank Size: XS, S
Shimano Dura-Ace R9200, 52/36, 165 mm length
Size: M
Shimano Dura-Ace R9200, 52/36, 170 mm length
Size: ML, L
Shimano Dura-Ace R9200, 52/36, 172.5 mm length
Size: XL
Shimano Dura-Ace R9200, 52/36, 175 mm length
Bottom bracket Praxis, T47 threaded, internal bearing
Cassette Shimano Dura-Ace R9200, 11-30, 12-speed
Chain Shimano Dura-Ace/XTR M9100, 12-speed
Max. chainring size 1x: 54T, 2x: 56/43

Wheels

Wheel front Bontrager Aeolus RSL 51, OCLV Carbon, Tubeless Ready, 51 mm rim depth, 100×12 mm thru axle
Wheel rear Bontrager Aeolus RSL 51, OCLV Carbon, Tubeless Ready, 51 mm rim depth, Shimano 11/12 freehub, 142×12 mm thru axle
Skewer front Bontrager Switch chamfered thru axle, removable lever
Skewer rear Bontrager Switch chamfered thru axle, removable lever
*Tyre Size: XS, S, M, ML, L, XL
Bontrager Aeolus RSL RD, Tubeless-Ready, cotton construction, aramid bead, 170 tpi, 700×28 mm
Size: XS, S, M, ML, L, XL
Pirelli P Zero Race, 120 tpi, tubeless-compatible, 700×28 mm
Tyre part Bontrager TLR sealant, 180 ml/6 oz
Max tyre size 32 mm (as measured, see manual for details)

Components

*Saddle Size: XS, S
Aeolus RSL, carbon rails, 155 mm width
Size: M, ML, L, XL
Aeolus RSL, carbon rails, 145 mm width
*Seatpost Size: XS, S, M
Madone aero carbon seat post, 0 mm offset, short length
Size: ML, L, XL
Madone aero carbon seat post, 0 mm offset, long length
*Handlebar/stem (integrated) Size: XS
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 35 cm control width, 38 cm drop width, 80 mm stem length
Size: S
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 37 cm control width, 40 cm drop width, 90 mm stem length
Size: M
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 90 mm stem length
Size: ML, L
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 100 mm stem length
Size: XL
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 41 cm control width, 44 cm drop width, 110 mm stem length
Rotor size Max brake rotor sizes: 180 mm front, 160 mm rear

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
