2024 Trek Domane+ Al 5 Trek Black 1

2024 Trek Domane+ AL 5 – Trek Black Frame

Price range: $92.30 through $93.00

Quantity
SKU: N/A Category: Brand:

Description

The Domane+ AL 5 is a lightweight alloy e-road bike that delivers an authentic road bike feel with the benefit of an electric boost. The intuitive and natural-feeling HyDrive pedal assist system lets you keep pace with friends, crush hilly terrain or push yourself harder on training rides.

*Please note – spec applies to all sizes unless listed separately

Frameset

Frame 100 Series Alpha Aluminium, hub drive system, tapered head tube, internal routing, flat-mount disc, rack and mudguard mounts
Fork Domane+ carbon, tapered alloy steerer, internal brake routing, mudguard mounts, flat mount disc, 12×100 mm thru axle
Frame fit Endurance

Weight

Weight 56 – 14.06 kg / 31 lbs
Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).

E-system

Battery 250 Wh, integrated in down tube
Charger 2A, 42V output, 100V–240V AC input

Drivetrain

*Shifter Size: 49, 52
Shimano 105 R7025, short-reach lever, 11-speed
Size: 54, 56, 58, 61
Shimano 105 R7020, 11-speed
Front derailleur Shimano 105 R7000, 31 mm clamp
Rear derailleur Shimano 105 R7000, long cage, 34T max cog
*Crank Size: 49
FSA Vero Pro, 50/34, 165 mm
Size: 52
FSA Vero Pro, 50/34, 170 mm
Size: 54, 56
FSA Vero Pro, 50/34, 172.5 mm
Size: 58, 61
FSA Vero Pro, 50/34, 175 mm
Bottom bracket Torque sensor, threaded, 110 mm spindle
Cassette Shimano 105 HG700-11, 11-34, 11-speed
Chain Shimano HG601, 11-speed
Max. chainring size 2x: 50/34

Wheels

Hub front Formula RX-812 alloy, sealed bearing, 6-bolt, 100×12 mm thru axle
Skewer front Bontrager Switch thru axle, removable lever
Hub rear Hyena hub drive motor, 40 Nm, 250 W
Rim Bontrager Paradigm, Tubeless Ready, 28-hole, 21 mm width, Presta valve
Tyre Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700×32 mm
Max tyre size 38mm without mudguards, 32mm with mudguards

Components

*Saddle Size: 49, 52
Bontrager Verse Short Comp, steel rails, 155 mm width
Size: 54, 56, 58, 61
Bontrager Verse Short Comp, steel rails, 145 mm width
Seatpost Bontrager carbon, 27.2 mm, 8 mm offset, 330 mm length
*Handlebar Size: 49
Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal Di2 routing, 75 mm reach, 128 mm drop, 38 cm width
Size: 52
Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal Di2 routing, 75 mm reach, 128 mm drop, 40 cm width
Size: 54, 56
Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal Di2 routing, 75 mm reach, 128 mm drop, 42 cm width
Size: 58, 61
Bontrager Elite IsoZone VR-SF, alloy, 31.8 mm, internal Di2 routing, 75 mm reach, 128 mm drop, 44 cm width
Handlebar tape Bontrager Supertack Perf tape
*Stem Size: 49
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
Size: 52, 54
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
Size: 56, 58
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length
Size: 61
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length
Head set FSA Integrated, sealed cartridge bearing, 1-1/8″ top, 1.5″ bottom
Brake Shimano 105 hydraulic disc, BR-R7170 flat mount caliper, resin pad w/fin
Brake rotor Shimano RT66, 6-bolt, 160 mm
Rotor size Max brake rotor sizes: 160mm front & rear

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
